Product number: YH-001-21

Cell model: 26650/3.2V/3.2Ah

Battery specifications: 26650/15S16P/48V/50Ah

Nominal voltage: 48V

Nominal capacity: 50Ah

Charging voltage: 54.75V

Charging current: ≤10A

Discharge current: 10A

Instantaneous discharge current: 40A

Discharge cut-off voltage: 41.25V

Finished product internal resistance: ≤200mΩ

Battery weight: 30Kg

Product size: 600×420×210

Charging temperature: 0～45℃

Discharge temperature: -20～60℃

Storage temperature: -20～60 ℃

Temperature protection: 65℃±5℃

Battery housing: cold-rolled sheet metal

Lithium battery protection: short circuit protection, overcharge protection, over-discharge protection, overcurrent protection, temperature protection, balancing, etc.

Application

Solar system

Telecom

Other energy storage areas

Features

Power display: Display the battery power through the display screen to intuitively understand the battery status;

Shockproof and dustproof: Cold rolled sheet metal, surface powder spraying treatment, internal filling shockproof structure, shockproof and dustproof.

Communication interface: RS485 communication protocol is used to read battery voltage, current, temperature, capacity and other information;

Data communication management: Software management chip, precise data transmission, precise temperature control are used to eliminate safety hazards to the maximum extent.

The battery pack is safe and has a temperature probe. The temperature exceeds the automatic start protection;

The battery pack has a high cycle life and meets the value concept of low carbon, energy saving and environmental protection;
