YH1200

A portable power station is a battery powered device that can provide power to various small electrical and electronic devices. It is essentially a large battery that can be charged and used to power or charge other devices, such as smartphones, laptops, cameras, and even small TVs or mini refrigerators. Portable power stations are typically used for camping or outdoor activities, emergency preparedness, or any place that requires power but does not have a ready-made outlet. They are usually equipped with various sockets, including USB ports, standard AC power sockets, and sometimes even DC power sockets for certain appliances or devices. The capacity of portable power stations is measured in watt hours (Wh), indicating how much electricity can be provided in a certain period of time. For example, a power station with a capacity of 600Wh can theoretically supply power to equipment using 600 watts for one hour, or to equipment using 60 watts for ten hours.
Message Contact Us
Details

Rated capacity: 1310.7Wh, 8 strings, 2 parallel units, 25.6Ah

Battery: BYD Lithium Iron Phosphate Battery Cell (51200mAh)

Voltage: 25.6V

Rated power: 1200W sine wave (bidirectional inverter) AC peak power: 2400W

AC output * 2:220V 50Hz 110V 60Hz maximum 1200W

DC function:

PD1 (type c) output: 5Vdc-3A/9Vdc-3A/12Vdc-3A/15Vdc-2A/20Vdc=2A (maximum 40W)

PD2 (type c) output: 5Vdc-3A/9Vdc-3A/12Vdc-3A/15Vdc-3A/20Vdc=3A/20Vdc=5A (maximum 100W)

USB-QC output * 2: 5V 3A/9V 2A/12V1.5A (maximum 18W)

DC5521 output * 1:12V5A (maximum 60W)

DC5525 output * 1:24V 4.5A (maximum 108W)

Cigarette lighter output * 1:12V 10A maximum 120W

Cigarette lighter+DC5521 (maximum 120W)

PD1+PD2+USB1+USB2: Maximum output power of 176W (according to PD protocol)

XT60 input: 12V-29V 150W (supports car charging mode, MPPT mode)

AC port charging input * 1: maximum input power of 900W

Battery display: LCD screen

LED light * 1: Approximately 3W illumination light

Bluetooth * 1 supports FM/MP3/supports external microphone (KTV mode)

Wireless charging: Apple 15W wireless charging, Android 5W (transmission power: 5W/7.5W/10W/15W; Conversion rate: 80%)

Weight: Net weight 12.7Kg/Gross weight 14.58kg

Size: 350x252x250mm

UN carton size: 442 * 338 * 345mm

Battery cycle life: ≥ 4000 cycles/70% EOL@25 ℃

Operating environment temperature: -15 ℃ to 45 ℃

Storage temperature: -10 ℃ to 60 ℃

Accessories: Instruction manual * 1 certificate of conformity * 1 AC charging cable * 1

Charging time: 1.5 hours
